50w Suitcase Pulse Laser Cleaning Machine
Product Description
The QYCL-FP50D portable pulse laser cleaning machine adopts 50W pulse fiber laser technology. It uses high-energy laser beams to instantly vaporize and decompose surface pollutants in nanoseconds, achieving non-contact, non-damaging precision cleaning. The whole machine adopts an integrated suitcase design (size 394*297*275mm), weighs only 11kg, and can be easily moved with one hand, truly realizing the industrial-grade cleaning freedom of "washing wherever you go".
The equipment is equipped with a 1kg ultra-light laser head, which is flexible and easy to operate. It can accurately process complex structural surfaces such as planes, curved surfaces, holes and seams, and perfectly solves the dead corner problem that is difficult to reach with traditional cleaning methods.
Products Advantages
1. Extremely portable design
2. Intelligent cleaning system
- Red light assisted positioning: accurately indicate the cleaning area to avoid misoperation.
- Four-dimensional parameter adjustment: power, frequency, pulse width, and scan width are adjustable.
3. Non-destructive cleaning
4. Super strong environmental adaptability
- Wide temperature range operation: stable operation in 0-45℃ environment
- Air-cooled heat dissipation system: say goodbye to bulky water tanks, energy saving and environmental protection
5. Green economic benefits
- Zero consumables cost, no chemical pollution, 100,000 hours of life
6. Full scene coverage capability
- Mold manufacturing-injection mold residue cleaning
- Metal processing-welding pretreatment/weld cleaning
- Cultural relics restoration-rust removal of stone metal cultural relics
- Rail transportation-wheel bearing degreasing
- Energy field-pipeline inner wall descaling
Product parameter
|
Model |
QYCL-FP50D |
QYCL-FP100D |
QYCL-FP200D |
|
Laser power (w) |
50 |
100 |
200 |
|
Single pulse energy (mj) |
1.1 |
1.7 |
1.5 |
|
Weight of hand-held head (kg) |
1 |
||
|
Power adjustment range (%) |
10-100 |
||
|
Width of scanning (mm) |
100*100 |
||
|
Focal length (mm) |
100/160/260 |
||
|
Central wavelength (nm) |
1060~1070 |
||
|
Cooling method |
Air Cooling |
||
|
Fiber length (m) |
3 |
||
|
Type of laser source |
Pulsed fiber laser |
||
|
Dimension of machine (mm) |
315*152*275 |
394*160*275 |
405*200*260 |
|
Weight of machine (kg) |
8.5±0.5 |
11±0.5 |
16±0.5 |
|
Power supply |
220V |
||
Product Details
Suitcase Structure Design
Small size, light, easy to carry, battery/external power supply two modes can be selected freely, it's not only suitable for small spaces, high altitude, field operations, etc., but also suitable for factory workshop operations.
Portable Cleaning Terminal
2D galvanometer structure, multi-pattern cleaning solution, small cleaning head is small and light, timely alarm, safe and reliable.
High-quality Core Components
Raycus/MAX/JPT/IPG laser, famous brand, customized Schneider/Omron/Chint First-class electrical brand, safe, stable and reliable.
Open Functional Design
Visual multi-language touch control screen, equipped with a variety of industrial bus communication protocol interface to real-time monitoring of the control system status, help users quickly locate and solve problems.
Product features
- Use new power pulsed laser technology with international standard portable laser cleaning technology.
- Precise cleaning to pinpoint and selectively clean objects with less sensitivity.
-
The operation interface provides 8 cleaning modes, which can be switched by clicking the scanning mode option on the interface (circular switching): Linear Mode, Rectangular 1 Mode, Rectangular 2 Mode, Circular Mode, Sine Mode, Double Helix Mode, Free Mode and Ring.
-
Language switch: Set the system language mode, currently supports 9 kinds including Chinese, Traditional
Chinese, English, Russian, Japanese, Spanish, German, Korean, French, etc.; - Cleaning efficiency saves time, no preparation or post-cleaning required.
Application
- Metal surface rust removal; graffiti removal.
- Surface paint removal and scale removal and paint removal.
- Surface stains, motor oil and edible grease almost all debris.
- Surface plating and powder coating.
- Welding NDT pretreatment of surfaces, joints and slag.
- Removal of mould and algae from stone and relic surfaces.
- Rubber moulds and metal castings.
Stainless steel cleaning
Rust cleaning
Mold cleaning
Oxide layer cleaning
Application Industries:
Mining, Rust Removal, Automotive and Marine Restoration, Filtration Cleaning, Machinery Maintenance, Metal Fabricators, Restoration Industry, Paint Stripping.
Company Profile
Shandong Qiangyuan Laser Of Sdiit Ltd.--Leader in Industrial Precision Cleaning Solutions
Founded in 2021, it is a national high-tech enterprise, focusing on the field of laser cleaning, with more than 50 independent intellectual property rights. It has passed ISO9001 certification and its products meet CE safety standards.
Four major guarantee systems:
R&D: Laser Research Institute of Shandong Academy of Sciences.
Production: The factory is located in Liaocheng City, Shandong Province.
Service: 7×24 hours response.
Training: Free training for engineers.
FAQ
Q1: Will the laser damage the metal substrate?
A: Through precise energy control technology, it ensures that the energy only acts on the surface contaminant layer and does not affect the material properties at all.
Q2: Can it clean non-metal surfaces?
A: This equipment is optimized for metal substrates and also performs well on non-metal surfaces such as rubber molds (tire industry) and stone carvings. Free sample service is provided.
Q3: Is the equipment maintenance complicated?
A: Maintenance is simple, and only the lens needs to be replaced regularly.
